Industrial 2ch Gigabit PoE Injector IEEE 802.3at 30W PoE+ Injector Power Over Ethernet Adapter + 120W 24V DC Power Supply DIN Rail Mount

Descriptions: The 2 Ports PoE+ Injector is a Industrial Gigabit PoE Injector allows you to connect the IEEE 802.3af/at PoE device such as access control, IP camera and access point with a non PoE switch within the distance of 100m. The Ethernet port and the PoE Out ports (to PoE device) supports 10/100/1000Base-T and are compliant with IEEE 802.3ab. The PoE Output ports compliant with IEEE 802.3af/at. The 2 channel POE adapter provides an integrated power solution with 12~48VDC or 9~36V AC wide range voltage input. Features: 12~48VDC or 9~36V AC Power Input 2 RJ45 Ethernet Data Input Port + 2 RJ45 Power Over Ethernet Output Port(Data + Power) Supports IEEE 802.3at Power over Ethernet(PoE+) Power Sourcing Equipment Total PoE power is 60W, max 60W at single port PoE output Supports 10/100/1000Base-TX Power Pin Assignment: 4/5(+), 7/8(-) Support DIN-Rail & Wall-mount installation. Extensive LED indicators for PoE diagnostics Environmentally Hardened -40°C to 75°C (-40°F to 167°F) operating temperature Warranty: 5-Year Warranty Package: 1 * 2 ports PoE+ Injector 1 * POE injector User Manual 1 * L-Shaped Wall Mount bracket 1 * 120W 24V Power Supply

• [120W 24V DC Power Included] – The 2 ports PoE injector support 24V DC Input and boost to 48V PoE output.
• [Small Size] – The 2Ch Gigabit PoE Injector housing size is 3.93x2.76x1.18in, it don’t need large room to install.
• [802.3af/at PoE Output] – The PoE+ inejctor with 2 PoE output Ports, supports IEEE802.3af PoE (15.4W) and IEEE802.3at PoE+(30W). It can connect 2 device at the same time.
• [802.3af/at PoE Output] – The PoE+ inejctor with 2 PoE output Ports, supports IEEE802.3af PoE (15.4W) and IEEE802.3at PoE+(30W). It can connect 2 device at the same time.
• [Din-Rail & Wall Mount] –The Gigabit PoE Injector come with 35mm Din-rail Clip and Wall mount accessories.
